RPS-PC35
Rps-sonic
RPS-PC35
35khz ultrasonic cutter for Cloth cutting Pocket slicing
What's the principle of ultrasonic cutting?
The principle of an ultrasonic cutter is completely different from conventional one. It uses the energy of ultrasonic to melt the material to be cut. Therefore, the ultrasonic cutting does not require a sharp cutting edge, nor does it require a large pressure, and does not cause any chipping or breakage. At the same time, since the cutting blade is subjected to ultrasonic vibration, the frictional resistance is particularly small, and the material to be cut is not easily adhered to the blade. This is particularly effective for cutting viscous and elastic materials, frozen materials such as food, rubber, etc., or objects that are inconvenient to apply pressure.
The ULTRASONIC TRIM KNIFE is a hand held, portable instrument designed for cutting, and trimming of prepregs and other hard to cut materials.
Ultrasonic cutting knife cut prepregs faster, more efficiently and with less fiber damage than conventional cutting methods, and are thereby more cost effective through greater productivity and reduced material waste. Ultrasonic energy is trigger activated providing operators with control over cutting pressure and the duration of ultrasonic activation. Accessories for remote operation of a Sonicut system in a machine mounting are available.
A 300 watt variable amplitude power supply offers control of the amplitude (blade stroke) for different materials and thicknesses. The system is capable of both constant and timed ultrasonic activation. A choice of steel, carbide, or titanium tips and blades provide the accessories necessary to complete a variety of composite cutting operations
Introduction:
Ultrasonic cloth cutting, usually used in sewing equipment, is used for pocket cutting. Ultrasonic cutting knife can perfectly replace laser cutting to achieve perfect edge banding and fast cutting.
Compared with laser cutting, ultrasonic cutting has the following advantages:
1. Under the premise that the cutting speed does not change, part of the cost can be saved.
2. The cut fabric will not be yellowed or burnt
3. No smoke will be emitted when cutting, and no smoking device is required.
Parameter
Frequency | 35Khz |
Frequency adjustment | Auto-tracking type |
Max. power output | 300W |
Power output | Infinitive adjustment |
Power supply | AC200V 50/60Hz |
Outer dimension (mm) | 120*120*380 |
Weight | 6kg |
Blade thickness | 1mm |
Target Materials
Down fabric
Cashmere fabric
Chemical fiber fabric
Seamless underwear fabric
Pure cotton fabric
Quick-drying clothing fabric
Tips:
The cutting knife replaceable, it is better buy some reserve knives.
