High Strength 20Khz ultrasonic Ribbon welding for TAPES & RIBBONS welding and cutting

The demand for adult hygiene products is constantly increasing. Discreet and comfortable products are high on demand. When it comes to incontinence products the main applications for ultrasonics are establishing a safe side seam and integrating elastic bands for the typical elastic leg cuff. Also, low-cost diapers are becoming more and more popular. They are cut and laminated in a simple but patented process using ultrasonics.
Frequency:
Power:
horn :
weight :
Availability:
Quantity:
  • RPS-R20
  • Rps-sonic
  • RPS-R20

 High Strength 20Khz ultrasonic Ribbon welding for TAPES & RIBBONS welding and cutting

Ultrasonic welding is an industrial technique where high-frequency ultrasonic acoustic vibrations are locally applied to workpieces being held together under pressure to create a solid-state weld. It is commonly used for plastics, and especially for joining dissimilar materials. In ultrasonic welding, there are no connective bolts, nails, soldering materials, or adhesives necessary to bind the materials together.


The applications of ultrasonic welding are extensive and are found in many industries including electrical and computer, automotive and aerospace, medical, and packaging. Whether two items can be ultrasonically welded is determined by their thickness. If they are too thick this process will not join them. This is the main obstacle in the welding of metals. However, wires, microcircuit connections, sheet metal, foils, ribbons and meshes are often joined using ultrasonic welding.


Ultrasonic welding is a very popular technique for bonding thermoplastics. It is fast and easily automated with weld times often below one second and there is no ventilation system required to remove heat or exhaust. This type of welding is often used to build assemblies that are too small, too complex, or too delicate for more common welding techniques.


 High Strength 20Khz ultrasonic Ribbon welding for TAPES & RIBBONS welding and cutting

Item Parameter
Frequency 20Khz
Power 2000W
Ceramice chips 4chips
Connect screw 3/8-24unf

微信图片_20210111155900

Kindly check the AMPLITUDE REFERENCE GUIDE for ULTRASONIC WELDING (in Microns (um)) table in the next page, you will find suit frequency for your application.


AMPLITUDE REFERENCE GUIDE for ULTRASONIC WELDING (in Microns (um))




Resin



Frequency

Amorphous

15Khz

20Khz

30Khz

40Khz

acrylonitrile Butadiene Styrene(ABS

36-84

30-70

24-56

18-42

Acrylonitrile Styrene Acrylate(ASA)

36-84

30-70

24-56

18-42

Polycarbonate(PC)

72-120

60-100

48-80

36-60

PC/ABS

72-120

60-100

48-80

36-60

Polycarbonate/ Polyester

60-120

50-100

40-80

30-60

Polyetherimide(PEl)

84-120

70-100

56-80

42-60

Polyethersulfone(PES)

84-120

70-100

56-80

42-60

Polymethyl Methacrylate(Acrylic, PMMA)

48-84

40-70

32-56

24-42

Polyphenylene Oxide(PPO)

60-108

50-90

40-72

30-54

Polystyrene(PS)

36-84

30-70

24-56

18-42

Polysulfone(PSU

84-120

70-100

56-80

42-60

Polyvinyl Chloride(rigid PVC)

48-96

40-80

32-64

24-48

Styrene-Acrylonitrile (SAN)

36-84

30-70

24-56

18-42

Semi-Crystalline





Cellulosics(CA, CAB, CAP)

72-120

60-100

48-80

36-60

Liquid Crystal Polymer(LCP)

84-144

70-120

56-96

42-72

Polyoxymethylene, Polyacetal(POM)

84-144

70-120

56-96

42-72

Polyamid(Nylon, PA)

84-144

70-120

56-96

42-72

Polybutylene Terephthalate(Polyester, PBT)

84-144

70-120

56-96

42-72

Polyethylene Terephthalate(Polyester, PET)

96-144

80-120

64-96

48-72

Polyetheretherketone(PEEK)

84-144

70-120

56-96

42-72

Polyethylene(PE)

108-144

90-120

72-96

54-72

Polyphenylene Sulfide(PPS)

96-144

80-120

64-96

48-72

Polypropylene(PP)

108-144

90-120

72-96

54-72


Rps-sonic, consisted with a couple of young people who love ultrasonic very much.The founding members of RPS-SONIC have an average degree of Bachelor's degree or above. They have been in the ultrasonic industry for more than 5 years and have rich experience in ultrasound. The company's business philosophy is: Do not blindly promote any product, find the right product for the customer. So before each order, we will confirm all the details, including application details, equipment conditions, equipment specific information.

Before year 2012, we only sale second branson / dukane / rinco / herrman/telsonic welding equipment , during these twenty year develop, we find, more and more people have problem with the core part of ultrasonic welding equipment -generator and transducer, so we decided to start our business of transducer and generator of our own transducer and generator. Many of the end user meet the transducer problem, they don’t know why transducer broken, and changing the expensive transducer one by one. Actually, one branson /dukane /rinco transducer can use 10~30 year, even the cheapest transducer can use about 5 years. So there must some reasons if your transducer broken in one year. That’s why we want build Rps-sonic, we need to help more end user to know more about transducer , to use ultrasonic equipment better, to save cost when meet problem.


Unreasonable operation may shorter the use-life of ultrasonic generator. So we have to make technical inquiry before operate ultrasonic welding machine. The key point of ultrasonic machine is resonance, only keep every part in resonance can make the system in best work environment.

We are committed to developing a more stable ultrasonic generator, which minimizes the failure rate of the box and escorts your production process.
