I. How is ultrasonic atomization equipment connected to a tube furnace?

In fields such as nanomaterial preparation, functional ceramics R&D, catalytic material synthesis, and advanced materials research, researchers often need to convert liquid precursors into fine droplets and then introduce them into a high-temperature environment for thermal decomposition, oxidation, crystallization, or material deposition.

An integrated system combining ultrasonic atomization/spraying equipment with a tube furnace is designed specifically to meet these process requirements.

The system uses ultrasonic vibration to convert liquid into tiny droplets and then employs a carrier gas or a specially designed delivery structure to transport the resulting aerosol into the reaction zone of the tube furnace. Under high-temperature conditions, the droplets undergo solvent evaporation, precursor decomposition, or other chemical reactions, ultimately forming powders, particles, or deposited materials—with the specific product determined by the precursor and process conditions.

Compared to standard atomization equipment, the key to this integrated solution lies not merely in generating droplets, but in achieving a seamless, continuous process flow that encompasses liquid supply, ultrasonic atomization, aerosol transport, and high-temperature reaction.

II. Working Principle: From Liquid Atomization to High-Temperature Material Preparation

A typical integrated ultrasonic atomization and tube furnace system comprises the following components:

**Ultrasonic Atomization Unit:** Converts liquid into fine droplets.

**Precision Liquid Supply System:** Controls the feed rate and stability of the precursor.

**Tube Furnace Interface:** Connects the atomization device to the furnace tube and provides a suitable transport channel for the aerosol.

**Carrier Gas System:** Transports the aerosol according to process requirements and controls the reaction atmosphere.

**Tube Furnace Heating System:** Provides the designated high-temperature reaction environment.

**Control and Monitoring System:** Manages liquid supply, atomization, gas flow rates, and furnace temperature.

**Product Collection and Exhaust Treatment System:** Collects powders or treats reaction exhaust gases as required by the process. The basic workflow is as follows:

Precursor solution → Ultrasonic atomization → Aerosol transport → High-temperature reaction in a tube furnace → Powder collection or material deposition

Ultrasonic atomization enables low-flow-rate liquid delivery under appropriate conditions. Droplet characteristics are influenced by various factors—such as atomization frequency, liquid viscosity, surface tension, solution concentration, and equipment configuration—requiring parameter optimization based on the specific material system.

III. Core Application: Ultrasonic Spray Pyrolysis

A key application combining ultrasonic atomization with a tube furnace is Ultrasonic Spray Pyrolysis.

In this process, a precursor solution containing the target elements is atomized, and the resulting aerosol is introduced into a temperature-controlled environment. There, it undergoes solvent evaporation, thermal decomposition, or chemical reactions to form the target material.

This process can be used to investigate:

Metal oxide powders

Nano- and micro-scale functional materials

Catalysts and catalyst supports

Functional ceramic materials

Optoelectronic materials

Battery and energy materials

Sensor-related materials

For example, researchers can use suitable metal salt precursors to explore preparation conditions for materials such as zinc oxide, titanium dioxide, iron oxide, or tin oxide.

The particle size, morphology, crystal structure, and composition of the final product depend not only on the atomization performance but also on furnace temperature, carrier gas flow rate, precursor concentration, reaction atmosphere, and residence time.

Therefore, properly matching the ultrasonic atomizer with the tube furnace is crucial for establishing a stable experimental process.

IV. Tube Furnace Interface Design: Determining System Stability

In practical applications, the connection structure between the atomizer and the tube furnace is critical.

If the interface design is flawed, issues such as unstable aerosol transport, premature droplet condensation, pipeline deposition, or furnace tube contamination may arise, even if the atomizer itself is functioning correctly.

When designing the interface, it is recommended to focus on the following aspects.

1. Interface Dimensions and Furnace Tube Structure

The interface must be compatible with the existing tube furnace's tube diameter, material, inlet configuration, and available installation space.

Custom connectors or aerosol delivery assemblies can be designed to suit specific furnace tube dimensions and structural configurations.

2. Aerosol Delivery Path

The delivery channel should minimize unnecessary bends, cold spots, and areas prone to liquid accumulation to reduce the risk of droplet deposition and condensation.

The specific design should be based on factors such as aerosol flow rate, liquid properties, and reaction temperature.

3. Carrier Gas and Reaction Atmosphere

The carrier gas influences not only aerosol transport but also the residence time in the reaction zone and the material formation process.

If the process involves oxidation, an inert atmosphere, or other specialized atmospheres, an appropriate gas control system must be configured to meet chemical reaction requirements.

4. High-Temperature Isolation and Safety

The atomization unit should generally not be directly exposed to the thermal load of the tube furnace's high-temperature zone.

Therefore, the distance between the atomizer and the furnace body, the interface materials, and necessary thermal insulation structures must be carefully designed to prevent heat conduction from damaging the atomization assembly.

Additionally, the interface and gas delivery lines must account for thermal expansion, sealing, pressure fluctuations, and potential hazardous exhaust gases.
